PET Bottle Water Filling Machine

PET bottle water filling machine is mainly used in drinking water, pure water, mineral water production line. Water filling machine adopts PLC to control the whole machine operation. Water filling machine capacity range starts from 5000BPH to 36000BPH by single one.

Brief Introduction

PET bottle water filling machine integrates washing, filling and capping. It’s full automatic in the whole process. PET bottle water filling machine is mainly suitable for the continuous operation of bottle washing, filling and sealing of mineral water, purified water, still water and other non gassy drinks. The original electrical component are made of foreign well-known brands, and all the places in contact with liquid materials are made of high-quality food grade stainless steel. The whole machine has high degree of automation, easy operation, wear resistance, stability and low failure rate.

Advantage

  • High accuracy
  • Long service life
  • High productive
  • Easy to operate
  • Long warranty
Product Features
Product Configurations
Product Parameters
Video

Product Features

1.Water filling machine has a compact structure, perfect control system, easy to operate and highly automated.

2.Only by changing the star-wheel and some parts can realize different bottle volume filling.

3.The parts touch with product is made of SUS316/304, anti-corrosive, and easy to clean.

4.Rapid flow, highly filling precision, nicety liquid level without liquid loss to satisfy the filling process demand.

5.The capping head adopts constant torque magnetic device to guarantee capping quality and impact cap.

6.Water filling machine has a high efficient cap arranging system, perfect cap feeding with self-control and self-protection device.

7.Water filling machine adopts perfect overload protective device can ensure the operator and machine safety.

8.Water filling machine control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.

9.Water filling machine configurations used world famous brand.

10.Water filling machine control is HMI touch screen connect, easy and clear for operators.

Product Configurations

NameSupplier
Main Motor & ReducerSEW-Germany
Rinsing PumpCNP-China
InverterSIEMENS-Germany
PLCSIEMENS-Germany
Touch ScreenSIEMENS-Germany
ContactorSCHNEIDER-France
Hot RelaySCHNEIDER-France
Air SwitchLEUZE/BANNER-Germany
Photoelectric SwitchBANNER-USA
Pneumatic ComponentsFESTO-Germany
Sliding BearingIGUS-Germany

Product Parameters

ModelWashing

Heads

Filling

Heads

Capping

Heads

Capacity

(Based on 500ml)

Bottle Diameter

(mm)

Bottle Height

(mm)

Dimension

(mm)

Power

(KW)

XGF14/12/514125500050-110186-3502360*1770*27001.5
XGF16/16/516165800050-110186-3502760*2060*27002.2
XGF24/24/8242481200050-110186-3502800*2230*27003.0
XGF32/32/8323281500050-110186-3503550*2650*27004.0
XGF40/40/104040101800050-110186-3504360*3300*27007.5
XGF50/50/155050152400050-110186-3504720*3545*27007.5
XGF60/60/156060153000050-110186-3505770*5288*270011.0
XGF72/72/187272183600050-110186-3506540*4800*270011.0
XGF80/80/228080224200050-110186-3507800*6380*270013.0
